IEC 60811-4-1:2004 and ISO 6964 Compliant Automatic Carbon Black Content Tester for Polyethylene Combustion Testing

IEC 60811-4-1:2004 and ISO 6964 Compliant Automatic Carbon Black Content Tester for Polyethylene Combustion Testing
IEC 60811-4-1:2004 and ISO 6964 Compliant Automatic Carbon Black Content Tester for Polyethylene Combustion Testing IEC 60811-4-1:2004 and ISO 6964 Compliant Automatic Carbon Black Content Tester for Polyethylene Combustion Testing IEC 60811-4-1:2004 and ISO 6964 Compliant Automatic Carbon Black Content Tester for Polyethylene Combustion Testing IEC 60811-4-1:2004 and ISO 6964 Compliant Automatic Carbon Black Content Tester for Polyethylene Combustion Testing IEC 60811-4-1:2004 and ISO 6964 Compliant Automatic Carbon Black Content Tester for Polyethylene Combustion Testing IEC 60811-4-1:2004 and ISO 6964 Compliant Automatic Carbon Black Content Tester for Polyethylene Combustion Testing IEC 60811-4-1:2004 and ISO 6964 Compliant Automatic Carbon Black Content Tester for Polyethylene Combustion Testing IEC 60811-4-1:2004 and ISO 6964 Compliant Automatic Carbon Black Content Tester for Polyethylene Combustion Testing IEC 60811-4-1:2004 and ISO 6964 Compliant Automatic Carbon Black Content Tester for Polyethylene Combustion Testing IEC 60811-4-1:2004 and ISO 6964 Compliant Automatic Carbon Black Content Tester for Polyethylene Combustion Testing IEC 60811-4-1:2004 and ISO 6964 Compliant Automatic Carbon Black Content Tester for Polyethylene Combustion Testing IEC 60811-4-1:2004 and ISO 6964 Compliant Automatic Carbon Black Content Tester for Polyethylene Combustion Testing
Grundlegende Informationen
Herkunftsort: China
Markenname: Advanced Instruments
Zertifizierung: IEC 60811-4-1:2004 ; ISO 6964
Modellnummer: AIC-52032
Min Bestellmenge: 1 SATZ
Preis: $5000~$10000
Verpackung Informationen: Sperrholzkiste
Lieferzeit: 30 Tage
Zahlungsbedingungen: L/C,T/T,D/P
Versorgungsmaterial-Fähigkeit: 20 Sätze/Monat
Bestpreis Kontakt
Nach dem Service: Antwort in 12 Stunden und 12 Monaten Garantie: 1ganzes Jahr
Transportpaket: Sperrholzkiste Prüfstandard: IEC 60811-4-1:2004; ISO 6964
Gas: Stickstoff (Sauerstoffgehalt <0.5%), Sauerstoff Anwendung: Prüfung von Kabeln und Leitungen
Farbe: Grau Betrieb: Automatisch
Größe der Metallabdeckung: 300mm x 600mm x 1175mm Stromversorgung: AC220V, 50/60Hz, 16A
Explosionsbrenner: Nennleistung 1 kW Brenngerät: automatische Hochspannungszündung
Luftquelle: Propan und Druckluft Steuermodus: Touchscreen -Steuerung
Brennkammervolumen: ≥ 1 m³ Spezifikation: 600 mm × 450 mm × 750 mm
Quarzrohr: Innendurchmesser 30 mm, Gesamtlänge 450 mm; Flaschenwaschen: 500 ml, 2 Stück/Set
Brennendes Boot: Typ 77, 100 Stück/Set;
Hervorheben:

IEC 60811-4-1:2004

,

ISO 6964

,

Carbon black Test Device

General Introduction
1.1 Equipment overview

Carbon black content test device is designed and produced in line with GB/T2951.41—2008 <Common test methods for insulating and sheathing materials of electric and optical cables--Part 41: Methods specific to polyethylene and polypropylene compounds - Carbon black and/or mineral filler content measurement in polyethylene by direct combustion>, used for determination of carbon black content of polyethylene, polypropylene, polybutylene plastics.

1.2 Related standards
  • ISO 6964;
  • IEC 60811-4-1:2004
  • ASTM D1603

IEC 60811-4-1:2004 and ISO 6964 Compliant Automatic Carbon Black Content Tester for Polyethylene Combustion Testing 0

Technical parameters
  1. Quartz tube: inner diameter 30mm, total length 600mm;
  2. Heating furnace: room temperature~600℃, 500mm length;
  3. Temperature sensor: K type, room temperature~1300℃;
  4. Bottle washing: 500ml, 2 pcs/set;
  5. Burning boat: Type 77, 100 pcs/set;
  6. Air source: nitrogen (oxygen content <0.5%), oxygen (customer provided);
  7. Flow meter: 0.3~3L/min.
Technical specifications
  1. Overall Dimensions: 600mm*450mm*770mm
  2. Power supply: AC 220V, 50/60Hz, 16A
IEC 60811-4-1:2004 and ISO 6964 Compliant Automatic Carbon Black Content Tester for Polyethylene Combustion Testing 1
FAQ
  1. What's the delivery time?
    About 30days.
  2. What's your payment terms?
    30% paid by T/T in advance,70% paid by by T/T before shipping.
  3. What's your guarantee terms?
    The warranty of all products is 1 year.During this period,we are responsible for all faults caused by us.And we can supply life-long technical support.
  4. Can you supply training?
    We can supply training in our factory and online training for free.If onsite installation and training are required,please pay for tickets,accommodation and salary USD280/Day for every person.
